Trailer Model

4 Axle Low Bed Semi Trailer

Overall Dimension(Lx W x H)(mm)

16000*3000*1700 ( the height from ground to platform is 1200mm )

Loading Weight( KG)

80000-150000kg

Total Weight(KG)

10500

Axle Brand

4x16TON, FUWA   brand

Axle Number

Four

Suspension system

Common Mechanical suspension

Steel Spring

10/10/10/10 leaf spring suspension

The material of Main beam

The height of the beam is500mm,upper plate is18mm,down plate is 20mm,middle plate is 12mm.

Platform plate

3mm Diamond plate

Tire Type and quantity

1100R20 Tyres appear type 16units

Traction Pin

JOST brand,  90mm or 50mm

Spare Wheel Bracket

2 pieces

Tool Box

1 Standard

Landing Gear

Standard 28Ton

Brake system

Dual Line braking system ,

WABCO emergency relay valve

Brake air chamber

Two double and two single chamber

Electrical system

1.Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)

Tail lamp with turn signal, brake light & reflector, side lamp etc.

One set 6-core standard Cable.

Side Guard

According to customer’s requirement

Painting

optional

Packing

Polish with wax before shipping
